Overview

Basic Info.

Model NO.	SC200/200
Maximum Lifting Height	120 Meters
Chain Falls	2
Certification	CE, ISO9001:2000
Condition	New
Color	Orange
Transport Package	Containers
Origin	China
HS Code	8428200000
Production Capacity	2000

Product Description

Overview

1. construction elevator ranks among top 3 in terms of production and sales volume in China, with the highest price-performance ratio. Product range covers 2-wheel drive, 3-wheel drive, and variable frequency products. The new 3-wheel drive features more energy-saving and fuel consumption with the same configuration.

2. will purchase 200,000 ton raw materials from famous plants each year, which guarantees the product quality and favorable prices.

3. has the sole CNC cutting, stamping, and automatic robot welding line for standard section production in China. The main limb of the standard section adopts φ76×6 Q345B high frequency welding steel pipes, featuring high strength, good wear resistance, high straightness. The horizontal brace of the standard section adopts Q345B steel plate stamping and bending technology, which enables higher bearing capacity and straightness of the rack, higher product performance and longer service life.
Specifications

No	Items	Unit	Parameters	Remarks
1	Rated load		2×2000	Double cage
2	Rated load of installation/dismantle		2×1000	Double cage
3	Rated lifting speed	m/min	0~75	Drive ratio of reducer 1:14
4	Max. Lifting height	m	300
5	Cage size (LxWxH)	m×m×m	3×1.5×2.4
6	Cage bottom height	m	0.46
7	Wall clearance of framework	m	≤9m
8	Height of guide rail overhang	m	≤9m
9	Voltage	V	380V±5%
10	Motor power	kW	2×3×20	JC=25%
11	Frequency converter	kW	75
12	Rated operating current	A	2×3×60
13	Weight of standard section		150(166)	650mm×650mm×1508
14	Weight of single cage (incl. drive system)		1830
15	Machine weight	t	30.3	H=200m
16	Safety device model	SAJ50-2.0

After Sales Service

1. We have inistallation team in many countries as we offered professinal training for our client through 15 years experience.
2.We offer spare parts all year round and you may borrow from our local clients for any ugent cases.
3.Our technician are here for you all the time except New Year holiday,and video call makes the installation/repair process become very easy.

FAQQ: Are you a trading company or a factory?
A: We are a Manufacture with 15 years experience. We have both the price advantage of the factory and the thoughtful service of the trading company; and the advantage of taking responsibility
Q: How long is your delivery time?
A: If the goods are in stock, usually 5-10 days. Or if the goods are not in stock, then 15-20 days, depending on the quantity
Q: Do you provide samples ? A: In this field, we seldom provide samples, but it depands. We have project case in most countries like :United States / Australia/ New Zelan/ Bahrain/Dubai etc.
Q:Why choose us?
A: First,our product quality assurance and warranty for one year, steel structure warranty for life :15 years
Q1: How many countries have you exported your products to?
A1:Our product had exported to more than 20 countries, such as Korea, Vietnam, Philippines, Indonesia, India, Sri Lanka, Cambodia, Russia, Kazakhstan, Brazil, Algeria, Ukraine, Turkey etc.
Q2: How to confirm a suitable construction hoist model?
A2: My dear friends, please tell us the below basic parameters to confirm hoist model:a. Building height.b. Max load capacity .c. Other Special requirements
Q3: Can you install the hoist for us
A3: Yes, we can send one engineer to your country for installing, but you should bear the cost.
Q4: Warranty time?
A4: 12 month from the shipping day (except the wearing parts).Any other questions message now ! hope can cooperate with you! and welcome to visit us!
